CONFIGURATION

Chip Set solution

MSD638

PCB

Separated

CPU Core

1.2GHz Core ARM Cortex A53

GPU Core

450MHz Mali-720 MP2

DDR3 (GB)

1

EMMC (GB)

8

Storage card type

TF CARD

WLAN

802.11b/g/n

SCREEN SHARE

Smart Mobile Link (MHL 3.0)

for 4K video output from a micro-USB port

Miracast

Mobile → TV Mirroring feature Miracast

WiDi

(Wireless Display); Feature that allows to see the content on

PC which equipped with Intel WiDi on TV

WIFI

YES

WIFI Hotspot

YES

AV System

PAL/NTSC

UI

Android 7.0

Slim PCB

YES

Smart TV

YES

BROADCASTING SYSTEM

Cable/ DVB-T2

YES

PANEL

Backlight Unit

DLED

Panel Size (inch)

65-inch

Display Resolution (px)

3840 x 2160

Resolution

(UHD 4K x 2K), RGB

Aspect Ratio

16: 9

Response Time (G to G)

8ms

Refresh Rate

60Hz

Module Brightness (cd/m2)

230-280 (typ.)

Dynamic contrast ratio

4000:1

Viewing Angle(H/R,CR>=10) (TYP)

178°/178°

TERMINALS

Cable/Antenna Input

1

HDMI input

2

Component (YPbPr) input

1

Composite(AV) input

1，1 combined with Y

Audio Input L-R

1

PC in (D-sub)

1

Headphone Output

1

USB 2.0

2

Microphone interface

USB Mic

Ethernet (LAN)

1

TF Card Slot

1

TV PICTURE/AUDIO/POWER

Backlight Adjustable

Yes (0~100)

Backlight scan effect

240Hz motion screen + 240Hz chip

Color Temperature

Normal/Cold/Warm

Picture Mode

Standard, Vivid, Soft, User, Dynamic

Color Space gamma

YES, 80%

Picture Size

Auto, 16:9, 4:3

Comb Filter

Yes

Dynamic Noise Reduction

Yes

3D Deinterlace

Yes

Sound Mode

Standard, User, Movie, Sports, Music

Surround Mode

YES

Stereo System

NICAM /A2

Dolby sound

YES

Audio Output Power

≥2 x 5W
